Reolink RP-PN16 16-Port PoE NVR (Up to 24 Cameras)
Official Goods
- Official HK version with manufacturer warranty
- 100% brand new
- Kwun Tong physical store — enquiries & payment in store (by appointment)
- HK compatible
Check Stock & Delivery on WhatsApp
Message us before purchase · Usually reply within minutes
Pay in store
Pickup available at Elechid
Usually ready in 24 hours
Built for larger shops, offices and warehouses with more cameras to run. Sixteen PoE ports power and connect wired Reolink cameras, two hard-drive bays keep recordings on site, and the system scales to 24 cameras.
Key features
- 16 PoE ports, up to 24 cameras: Connect up to 16 PoE or plug-in Wi-Fi cameras plus 8 battery Wi-Fi cameras, or up to 24 battery Wi-Fi cameras, at up to 16MP.
- Two drive bays, up to 32TB: Two internal SATA bays take up to 16TB each. Recordings can be encrypted so they need a password to play back, even after a factory reset.
- Heat maps and AI search: Heat mapping shows where people move and linger, and keyword search finds specific clips. Search, perimeter and object alerts also need compatible cameras.
Specifications
| Camera inputs | Up to 24 IP cameras (max. 16 wired), up to 16MP |
|---|---|
| PoE | 16 × 10/100 Mbps PoE ports, IEEE 802.3af/at, max. 25 W per port |
| Network | 1 × 10/100/1000 Mbps RJ45 (LAN/WAN); 400 Mbps incoming / outgoing bandwidth |
| Video output | 1 × HDMI (up to 3840 × 2160), 1 × VGA (up to 1920 × 1080) |
| Audio output | 1 × RCA |
| Video compression / playback | H.265 / H.264; synchronous playback up to 9 channels |
| Storage | 2 × SATA bays, up to 16TB each (32TB total); no eSATA |
| Smart features | Heat map; AI video search; person, vehicle, non-motorised vehicle, animal, package detection; line crossing, zone intrusion, loitering; object removal / forgotten object (beta) – with compatible cameras |
| Other ports | 2 × USB 2.0; no alarm in/out |
| Users | 20 accounts; up to 12 simultaneous streams (2 main + 10 sub) |
| Power / environment | DC 52V 2.3A; -10°C to 45°C, 10–90% humidity |
Warranty and delivery
This is Hong Kong licensed stock, covered by the local distributor's warranty; the period is shown on the warranty card in the box. Brand new. Stock can be viewed at our Kwun Tong showroom by appointment.
Delivery by SF Express, freight collect. Free self-collection at our Kwun Tong shop (11:00–19:00). For other arrangements, please WhatsApp us.
